Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal

Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal

  • Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal
  • Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal
  • Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal
  • Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal
Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal
Product Details:
Place of Origin: China
Brand Name: SPIRITLASER
Certification: Medical CE/ROHS
Model Number: IE-11
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Aluminium alloy case and custom foam
Delivery Time: 5-7 working days after received your payment
Payment Terms: T/T or western Union or Paypal or MoneyGram
Supply Ability: 300 units per month
Contact Now
Detailed Product Description
Screen: 10.4" Movable Color Touch Screen Handpieces: 2
Connectors: CPC Plug-and-play Color: : White And Brown
SHR Fast Hair Removal: Yes YAG Laser Tattoo Removal: Yes
Certification: Medical CE/ROHS Type: Multi-Function Beauty Equipment
High Light:

home ipl machine

,

e light beauty machine



Portable E Light IPL Machine Hair Removal and Tattoo Removal with HIgh Energy For Beauty Salon

Model No.: IE-11

2 IN 1 SHR & ND YAG Laser Module



1. Best quality !~

2. Best effects !~

3. Best service !~

4. Best price !~



Quick Detail:



1. 2 in 1: SHR for fast hair removal permanently and Q-switch ND YAG Laser for tattoo removal
2. 2 handpieces: SHR handpiece (15X50mm or 10X40mm) + ND YAG laser handpiece (532nm and 1064nm; 1320nm optional)
3. High Energy with high quality seperate main power supply: 3000W

4. High Frequency: Both SHR and ND YAG laser are can reach 10HZ

5. Portable machine, convenient, white+Gray color, Multifuction machine





Technical Specifications:


A. General Specification



Screen: 10.4'' Movable color LCD touch screen
Output power: 3000W
Multi software languages
Cooling system:  semiconductor+ air + water + cooling gel
Skin Cooling: -6 ℃ ~ 0 ℃
Voltage: 100~240V
Machine's size: 58X50X39cm
Package size: 71X59X58cm
N.W.: 31KG
G.W.: 48K



B. SHR system



Wavelength: 640-950nm
Energy Density: 1-50J/cm2 adjustable
Spot size: 10x40mm, 15x50mm optional
Pulse duration: 1-7ms
Pulse: single
Pulse Repetition Rete: 1-10HZ



C. ND YAG laser



Laser type: Q-SWITCH ND YAG LASER
Laser energy: Max. 1500mj
Pulse width: 1-3ns
Frequency: 1-10HZ
Wavelength: 1064nm/532nm (1320nm for skin rejuvenation optional)







Work Theory



SHR
  • SHR works by gradually heating the dermis to a temperature that effectively damages the hair follicles and prevents re-growth, while avoiding injury to the surrounding tissue. A high repetition rate of short pulses are delivered deep into the dermis, achieving high average power and therapeutically effective heat build-up, with virtually no pain.

ND YAG Laser
  • The energy of Q-switched Nd:YAG laser can be absorbed by pigment of target tissue like tattoo, speckle, birthmark and so on.The pigment will be fragmented so small that they can be metabolized by the lymphatic system or egested out of the body. Thus the tattoo or other pigmentations will be removed without damage to normal tissue. The treatment is safe and convenient without downtime and side effects.



Applications and Effects

  • Fast hair removal permanently
  • Tattoo removal
  • Pigment removal
  • Skin rejuvenation
  • Nevus removal
  • Nevus of Ota removal
  • Speckle removal
  • Birthmark remmval



Contrast Photos (Before & After)

 Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal 0

Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal 1



Main Features:



1. Output power 3000W, which can provide enough power for SHR and ND YAG laser working.



2. SHR:

A. 10HZ, 10 shots in one second, fastest treatment speed

B. special wavelength : 640nm~950nm for no pain hair removal, more focus and more professional

C: Big spot size (10X40mm, 15X50mm optional) for big range treatment, can save much time for operators

D: Class A sapphire to provide strong contact cooling, during treatment, which can make the customer feeling more comfortable



3. ND YAG Laser:

A. 1064nm Wavelength: Remove black and dark blue tattoo pigments, such as tattoos, eyebrows, dark color around the eyes, freckle, age spot etc;

B. 532nm Wavelength: Remove red and brown tattoos and red mark.

C: 10HZ, faster than common laser.



Why choose IE-11 SHR+ND YAG Laser machine?



1). New Design, More convenience, safer

  1. 10.4’‘ Movable color touch screen, all parameters setup can be finished easily here
  2. Work a longtime with high energy, beauty salon first consideration
  3. Simple design, internal modular design, easy installation and maintenance
  4. User friendly software, easy operation
  5. Multi-language for your choice
  6. Alarm protection system of water flow and water temperature, stop all working immediately in case of any risk at the first time, offering a safe operation to you



2). Free LOGO service : Add your LOGO on start screen for promoting your brand.



3). CPC connector : High quality, safer, no water leak.



4). More Combinations for you choose: the model also have OTHER 8 x VERSIONS as following:
1. SHR+YAG (The above introduction)
2. SHR+IPL
3. IPL+YAG
4. SHR+IPL+YAG
5. SHR+E-LIGHT
6. E-LIGHT+YAG
7. SHR+E-LIGHT+YAG
8. IPL+RF
9. E-LIGHT+RF



5). Delivery: It can be shipped by DHL, Fedex, UPS, TNT, by air, by sea, or other ways customers named.



6). Power Plugs : Any power plugs as per your requirements !



Accessory List:

  • SHR handpiece X1
  • Laser handpiece X1
  • SHR goggle X1
  • Laser goggle X1
  • Eyepatch X1
  • Laser heads X2
  • SHR holder X1
  • Laser holder X1
  • Foot switch X1
  • Funnel&water pipe X1
  • Keys X2
  • Power Line X1



Portable E Light IPL Machine / Q-switch ND YAG Laser For Tattoo Removal 2
