| Place of Origin: | Beijing, China |
| Brand Name: | NUBWAY |
| Certification: | CE |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Aluminum Package |
| Delivery Time: | 3-5 Working Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 150-200 Sets /Month |
Treatment Scope:
A. Removal endogenous pigment: Nevus of Ota, coffee spot, age pigment, freckle etc
B. For exogenous pigment: Tattoo of body, eyeline and eyebrow
C. Skin whitenning
D. Remove striae gravidarum
Technical Parameter:
| Dimensions | 920× 555 ×1065mm not including joints arm |
| Weight | 100kg |
| Wastage power | 800VA |
| Fuse | 220V, 10A |
| Output mode | Q-switch Pulsed output |
| Wavelength | 1064nm, 532nm |
| Pulse Duration | 10±3ns |
| Frequency | 1Hz, 2Hz,5Hz |
| Single Pulse energy | 250mJ-1500mj |
| Safety distance | NOHD 1km. Operator must wear goggles |
| Cooling system | Water cooled |
| Work mode | Continually work with intervals |
| Spot Size | Continually adjustable |
Optical and electrical performance
| Energy of single pulse | 250mj-1500mj |
| Unstable output range | ST≤±10% |
| Output repeat | Rj<10% |
|
Error of expected energy and practical energy |
≤±20% |
| Spot diameter | 1-4mm adjustable |
| Focus error | ≤±0.5mm |
| Pc output power of collimate laser | 0.1mW≤Pc≤5mW |
| Adjustable range of Joints arm | Horizontal ≥45o Uprightness 60cm-80cm |
Spare parts:
Working Principle:
The Q-switched ND: YAG laser delivers light of specific wavelengths with high energy which are absorbed by the pigment in the tattoo and result in a shockwave. The shockwave shatters the pigment particles, releasing them from their encapsulation and breaking them into fragments small enough for removal by the body. These tiny particles are then eliminated by the body. Since this specific wavelength can only be absorbed by pigment particles, no injury to skin and normal tissues will occur.
Before-After Pictures:
Performance Guideline:
Pigmented lesion: Yiteng lentigines, Taitian Lentiines, freckles, eyebrow tattoo, body tattoo, lips tattoo.Vascular lesion: Pigment with red, brown, blue and black; vascular expanding
Make sure whether the clients’ skin is keloid skin, and learn whether they have purified their eyebrows, pigment with other means.
Explain to client that after riding of pigment still having pigment trace left which previously caused by sunburn.
Let clientele know that even after riding of the black and blue pigments still having brown and red left for the presence of composite painting material.
Better shave the client’s eyebrow for easy operating before the treatment.
1. 3 years warranty with lifetime free service and maintenance.
2. Free training for operation of the equipment in our company, which provided by our specialized training department.
3. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the laser equipment, and after-sale maintenance and more.
4. OEM/ODM services are available. We have our own developing and design department and manufacturing line, which ensure your required beauty equipment.
5. Professional after-sale service team, solve all problems in time.
1. Can you treat all colours?
No. Light is measured in nanometres and there are two wavelengths of light that are emitted from this laser C one is invisible infrared light (1064nm) and the other is visible green light (532nm). The infrared wavelength is preferably absorbed into black and dark blue inks, whereas the green light is absorbed by red ink. It is possible to treat some other colours although white, yellow and bright colours are difficult. This is not usually a problem however, as lighter colours cover very easily. If you wish to cover-up an existing tattoo then the darker colours will be faded or removed, allowing you greater choice of size and colour of the cover- up design you choose.
2. Will the tattoo be removed in one treatment?
No, that is very unlikely. The light can only shatter a certain amount ink in one treatment, so several treatments are needed at 4-6 weekly intervals to work through the layers. You will notice the tattoo fades
more and more with every treatment you have. A test patch will be performed before a full session goes ahead to check how you react to the treatment. A professional tattoo can take between 4 C 5 treatments and sometimes only take 1 or 2. There are several factors that
