| Place of Origin: | Beijing, China |
| Brand Name: | NUBWAY |
| Certification: | CE |
| Model Number: | NBW-MI |
| Screen Size: | 10.4 Inch |
|---|---|
| Spot size: | 12*20mm(Diode Laser)/16*50mm 8*34mm(IPL) |
| Cooling system: | Semiconductor+built-in water+Air Cooling triple cooling systems |
| Input Power: | 1800W |
| Frequency: | 1-10HZ |
| Net weight: | 60kg |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Aluminum Package |
| Delivery Time: | 3-5 Working Day |
| Payment Terms: | T/T, West Union |
| Supply Ability: | 150-200 Sets /Month |
Treatment Scope & Effect(Diode Laser):
|
Laser type |
Semiconductor laser |
|
wavelength |
808 nm |
|
Output Mode |
pulse output |
|
Control Method |
Touch control |
|
Screen Size |
10.4 Inch |
|
Energy density |
10-75J/cm2 (Deviation≤±2%) |
|
Pulse width range |
1-400ms |
|
Spot size |
12*20mm |
|
Frequency |
1-10HZ |
|
Light spot surface temperature |
0-30°C |
|
Cooling System |
Semiconductor+built-in water+Air Cooling triple cooling systems |
|
Dimension |
500×425×1120mm |
|
Net weight |
60kg |
|
Fuse specification |
Ø5×2510A |
|
Input Power |
1800W |
|
Power |
AC220V±10% 10A 50HZ , 110v±10% 10A 60HZ |
| Wavelenth | HR:690nm,SR:560nm,VR:420nm |
| Discharge time | 1-3s |
| First pulse width | 0.1-15.0ms |
| Sub-pulse width | 0.1-15.0ms |
| Energy density | 20-50J/cm2 |
| Simmer time | 10-990ms |
| Supply power mode | AC220V,50HZ AV110V,60HZ |
| Spot size | HR:16mmX50mm SR/VR:8mmX34mm |
| Cooling system | Water,air,semi-conductor cooling |
| Power | 1800W |
| Security standard | MaxX10A |
| Cooling Temperature | -22℃~0℃ |
1. 3 years warranty with lifetime free service and maintenance.
2.Free training provided by our specialized training department.
3.On-line services, our skilled technique group will offer assistance in time.
4.OEM/ODM services, make sure to meet your requires.
5. Professional after-sale service team, solve all the problems for you.
Delivery Terms
1. How does the diode system remove hair?
This laser targets the pigment located in the hair follicle and shaft. The light is absorbed
by the pigment in the hair follicle and this energy is converted to heat which results in
damage to the hair follicle. This damage causes delayed re-growth of hair and, in most
cases, permanent destruction of many hair follicles. Unlike electrolysis, which disables
one hair follicle at a time, the laser reaches and treats hundreds of follicles at a time.
