skin care device

Item

Specifications

Screen

8-inch TFT Chromatic Touch Screen

2 kinds of handpieces

1. Elight handpiece with changeable auto-identify filters:

420nm/490nm/530nm/560nm/610nm/690nm~1200nm；

Spot size:40mm*8mm

1. IPL handpiece with fixed filter:

    Spectrum:690nm~1200nm

    Spot Size: 50mm*10mm

Handpiece connection

Fast connected

Radio frequency technical parameters:

RF energy level

1-9 (adjustable)

RF power

150W(Max)

RF frequency

1MHz

Number of RF Pulse:1;

       Pulse width scope: 250~450ms, each press changes10ms

       Energy level: 0~10,each press changes1;

       Delay of continual irradiance: 1~3s (adjustable), each press changes 0.5s

IPL technical parameters:

IPL energy level

15-50 (adjustable),each press changes1

IPL power

800W

IPL Pulses: 6 respectively adjustable pluses ;

       Pulse width: 0~10ms, each press changes 0.1ms;

       Pulse Delay scope: 0~100ms,each press changes1ms;

       Energy level: 0~50;

       Delay of continual irradiance: 1~3s, each press changes 0.5s;

5 skin types and 3 hair types treatment parameters

50,000 shots or 100,000 shots limitation for handpiece lifetime (Optional)

Electrical parameters:

Unexpected electricity prevention

Class I, Type B

Rated input power

1500VA

Power supply

AC220V±10%,50Hz±1Hz/

AC110V±10%,60Hz±1Hz;(Optional)

Size and weight:

Net weight of Host

52kg

Weight of each handpiece

2.5kg

Weight of package

20.5kg

Physical dimension of Host

300mm*300mm*1050mm

Physical dimension of Package

580mm*575mm*1165mm
